YoLink Smart Relay – YoLink Hub Required Fashion
Original price was: $25.59.$12.80Current price is: $12.80.
In Stock
Description
INTRODUCTION:
- Smart relay, can control electrical loads up to 5 amps at 120V (or control larger loads by using this relay to control other relays or contactors with sufficient voltage and current ratings)
-
- One normally-open dry set of contacts for control of electrical circuits or equipment devices
- Control-D2D Device-to-Device pairing allows for some functionality of devices even during the loss of WiFi, internet, and even power (battery-powered devices, only; this device is not battery-powered; requires a UPS or battery backed-up low-voltage power supply, for continued operation in power outages. See Related Devices for our battery-powered relay option)
-
- Works with the convenient and user-friendly YoLink app
- Extremely easy and fast installation using the YoLink app with Scan & Play
- Ready for manual control, automation ( if this, then that ) and schedules
-
- YoLink’s industry-leading long range communication allows for placing the relay in separate garage buildings, sheds, storage buildings, barns, greenhouses, etc.
-
- YoLink Hub with an internet connection (wired Ethernet or 2.4GHz Wi-Fi).
- Smartphone or tablet running iOS 9 or higher, Android 4.4 or higher
- Tools Required, Including But Not Limited to: Phillips screwdriver, slotted screwdriver, electrical tape, wire nuts, wire stripper tool, voltage multimeter or voltage tester tool
- Installation Difficulty Level: Moderate Easy
-
-
Outdoor Siren Controller: this completely wireless smart controller is capable of controlling 12VDC loads up to up 400 mA (or capable of controlling 12VDC coil relays that have contacts rated for larger loads)
-
YoLink Hub is required. Starting your first YoLink system? Consider one of our kits
- Your applications will vary, but any of our smart sensors, such as temperature humidity sensors, for example to control heaters and dehumidifiers, are suggested. All YoLink devices are compatible with our Hubs.
- Semtech® LoRa® RF Module YL09 microcontroller with 32-Bit RISC processor
- Color: White
- Input Voltage:5-24V DC
- Input Current: ≥ 300mA
- Device Current Draw: ≤ 60mA (on), ≤ 25mA (standby)
- Switched Current: 5A @120VAC @30VDC (Maximum)
- Dimension [L x W x D]: 2.09 x 1.93 x .98 inches (53.09 x 49.02 x 75.69 mm)
- Environmental:
- Temperature: -4°F – 122°F (-20°C – 50°C)
- Humidity: 5-85% non-condensing
- Intended for indoor use only
-
- (1) YoLink Relay
- (1) Quick Start Guide
-
-
The YoLink Relay is packaged with a quick start guide, only, for initial setup. Please download the current Installation & User Guide
PLEASE NOTE: -
The YoLink Relay is packaged with a quick start guide, only, for initial setup. Please download the current Installation & User Guide
PACKAGE CONTENTS:
TECHNICAL SPECS:
SUGGESTED PRODUCTS:
RELATED DEVICES:
-
Outdoor Siren Controller: this completely wireless smart controller is capable of controlling 12VDC loads up to up 400 mA (or capable of controlling 12VDC coil relays that have contacts rated for larger loads)
REQUIREMENTS:
APPLICATIONS:
BENEFITS:
FEATURES:
